| CODE |
D |
M |
T |
D1 |
H |
K |
FLOW |
FILTRATION AREA |
WEIGHT |
| inch |
mm |
m³/h |
cm² |
kg |
| MPD3/4 |
3/4 |
|
1/2 |
68 |
190 |
160 |
5 |
185 |
0,45 |
| MPD10 |
1 |
|
1/2 |
68 |
190 |
160 |
6 |
185 |
0,45 |
| MPD10S |
1 |
|
1/2 |
96 |
230 |
220 |
10 |
325 |
0,75 |
| MPD15 |
1½ |
|
1/2 |
96 |
230 |
220 |
15 |
325 |
1 |
| MPD15S |
1½ |
1/4 |
1/2 |
120 |
280 |
270 |
20 |
550 |
1,5 |
| MPD20 |
2 |
1/4 |
1/2 |
120 |
280 |
270 |
25 |
550 |
1,5 |
Filter Cleaning
The pressure difference between the inlet and outlet is observed manually from the manometers. If the pressure difference increases, the water flow is cut off and the system is stopped. Then remove the cover and take out the cartridge. For screen filter, the screen can be directly cleaned with pressurized water and reassemblied. For disc filter, loosen the the disc cartridge screw and clean the disc with pressurized water, then the filter can be reassemblied.
