DuCaR B 30 Metal

SKU: B30
Delivery date: 3-10 business days
Manufacturer: DuCaR Sprinklers

Double-nozzle, long throw, metal & brass, A+ uniformity, clean water irrigation sprinkler.


Water Input
:
1.5" Female BSP

Working Pressure
:
29 - 85 psi

Water Flow
:
100 - 391 l/min

Shooting Radius
:
17 - 31 m

Free Nozzles
:
8, 10, 12, 14 mm

Body Angle
:
27°

Box Dimensions
:
40x25x6 cm

Weight
:
1.5 kg

Sprayers
:
2

Material
:
Cast-Iron, Aluminium & Brass
US $72.00
US $101.00

IrrigationBox proudly presents DuCar Sprinklers! As an authorised distributor of DuCaR Sprinklers, we provide wide range of high quality irrigation equipment and guarantee 100% satisfaction!

Ducar B 30 Metal is a NEW model of our mid volume sprinklers which provides long shooting range with perfectly even distribution and uniformity at a great price!

Some unique benefits of DuCaR B 30 Metal sprinkler:

  • Comes with 4 different nozzles (12, 14, 16, 18 mm)
  • 2 Trajectories (Small one drives the sprinkler)
  • Runs on pressure range between 29 to 85 psi
  • Full and part (angle-adjusted) circle irrigation
  • Irrigates up to 62m diameter!
  • Lays down 6 to 23.5 tons of water per hour
  • Its 27° body angle reduces the effects of the wind more than 30° and 33° versions; conveniently used for any type of irrigation.
  • Provides perfectly even distribution with its ADJUSTABLE jet breaker from the sprinkler all the way out to the end of the throw
  • Replaceable nozzle ends and two-hole water outlets allow you to irrigate your field excellently by using minimum water
  • Great for any field crops and vegetables
  • Auto BRAKE system for keeping slow rotation speed on high pressure.
  • Full METAL Body and BRASS housing.
Technical Specifications

Nozzle Diameter Pressure Jet Length Capacity Values for a single sprinkler
Irrigated Area Rainfall per hour
mminchatmpsimfeetl/minm3/hG.P.Mm2acremm/h
8 .31 2 29 17 56 100 6,00 26 907 0,22 6,6
8 .31 3 44 19 62 120,8 7,25 32 1134 0,28 6,4
8 .31 4 56 21 69 141,7 8,50 37 1385 0,34 6,1
10 .39 2 29 18 59 130 7,80 34 1017 0,25 7,7
10 .39 3 44 21 69 160 9,60 42 1385 0,34 6,9
10 .39 4 56 22,5 74 185 11,10 49 1590 0,39 7,0
10 .39 5 70 24,5 80 208,3 12,50 55 1885 0,47 6,6
12 .47 2 29 19 62 168,3 10,10 44 1134 0,28 8,9
12 .47 3 44 22 72 206,7 12,40 55 1520 0,38 8,2
12 .47 4 56 25 82 241,7 14,50 64 1963 0,48 7,4
12 .47 5 70 27 89 270 16,20 71 2289 0,57 7,1
14 .55 2 29 21 69 216,7 13,00 57 1385 0,34 9,4
14 .55 3 44 24 79 266,7 16,00 70 1809 0,45 8,8
14 .55 4 56 26 85 308,3 18,50 81 2123 0,52 8,7
14 .55 5 70 28,5 93 350 21,00 92 2550 0,63 8,2
14 .55 6 85 31 102 391,7 23,50 103 3018 0,75 7,8

IrrigationBox proudly presents DuCar Sprinklers! As an authorised distributor of DuCaR Sprinklers, we provide wide range of high quality irrigation equipment and guarantee 100% satisfaction!

Ducar B 30 Metal is a NEW model of our mid volume sprinklers which provides long shooting range with perfectly even distribution and uniformity at a great price!

Some unique benefits of DuCaR B 30 Metal sprinkler:

  • Comes with 4 different nozzles (12, 14, 16, 18 mm)
  • 2 Trajectories (Small one drives the sprinkler)
  • Runs on pressure range between 29 to 85 psi
  • Full and part (angle-adjusted) circle irrigation
  • Irrigates up to 62m diameter!
  • Lays down 6 to 23.5 tons of water per hour
  • Its 27° body angle reduces the effects of the wind more than 30° and 33° versions; conveniently used for any type of irrigation.
  • Provides perfectly even distribution with its ADJUSTABLE jet breaker from the sprinkler all the way out to the end of the throw
  • Replaceable nozzle ends and two-hole water outlets allow you to irrigate your field excellently by using minimum water
  • Great for any field crops and vegetables
  • Auto BRAKE system for keeping slow rotation speed on high pressure.
  • Full METAL Body and BRASS housing.
Technical Specifications

Nozzle Diameter Pressure Jet Length Capacity Values for a single sprinkler
Irrigated Area Rainfall per hour
mminchatmpsimfeetl/minm3/hG.P.Mm2acremm/h
8 .31 2 29 17 56 100 6,00 26 907 0,22 6,6
8 .31 3 44 19 62 120,8 7,25 32 1134 0,28 6,4
8 .31 4 56 21 69 141,7 8,50 37 1385 0,34 6,1
10 .39 2 29 18 59 130 7,80 34 1017 0,25 7,7
10 .39 3 44 21 69 160 9,60 42 1385 0,34 6,9
10 .39 4 56 22,5 74 185 11,10 49 1590 0,39 7,0
10 .39 5 70 24,5 80 208,3 12,50 55 1885 0,47 6,6
12 .47 2 29 19 62 168,3 10,10 44 1134 0,28 8,9
12 .47 3 44 22 72 206,7 12,40 55 1520 0,38 8,2
12 .47 4 56 25 82 241,7 14,50 64 1963 0,48 7,4
12 .47 5 70 27 89 270 16,20 71 2289 0,57 7,1
14 .55 2 29 21 69 216,7 13,00 57 1385 0,34 9,4
14 .55 3 44 24 79 266,7 16,00 70 1809 0,45 8,8
14 .55 4 56 26 85 308,3 18,50 81 2123 0,52 8,7
14 .55 5 70 28,5 93 350 21,00 92 2550 0,63 8,2
14 .55 6 85 31 102 391,7 23,50 103 3018 0,75 7,8
Products specifications
Body Angle Medium Body Angle (23 ° to 30 °)
Water Input 1.5"
Circle Full & Part
Minimum Required Pressure 29 psi (2 bar)
Maximum Working Pressure 85 psi (6 bar)
Minimum Required Water Flow 100 l/min
Maximum Water Flow 400 l/min
Minimum Shooting Range 16 - 20 m
Maximum Shooting Range 30 - 40 m
Box Dimension 25x40x6 cm
Nozzles 12, 14, 16, 18 mm
Weight 1.5 kg
